MIL STD 810 Blowing Sand Dust Test Chamber
Name:MIL STD 810 Blowing Sand Dust Test Chamber
Interior Volume:1000L；
Air velocity: 1.5 -8.9m/s；
Concentration of dust:10.7±7g/ m³；
Dust particles : ＜ 150μm；
Air velocity: 18.0 -29.0m/s；
Concentration of sand:0.18+0.2g/m³；
Sand particles：149μm - 600μm, 600μm - 850μm；
Description
Xi'an LIB Environmental Simulation Industry is one of the most reliable manufacturers and suppliers of mil std 810 blowing sand dust test chamber in China, featured by quality products and low price. Welcome to buy CE approved mil std 810 blowing sand dust test chamber in stock here and get quotation from our factory. Contact us for discount information.
MIL STD 810 Blowing Sand Dust Test Chamber，Mil-std-810g is a U.S. military standard that deals with environmental testing of military equipment.
Sand Dust Test Chamber is to simulate the applicable ability of all kinds of products in the laboratory under the weather of flying sand and dust storm.
Specifications
| Name | MIL STD 810 Blowing Sand Dust Test Chamber |
Model | DIM-1000 |
Internal Dimension | 1000*1000*1000mm D*W*H |
Overall Dimension | 2800*3500*2000mm D*W*H |
Interior Volume | 1000L |
Blowing Dust | |
Air velocity | 1.5 -8.9m/s |
Concentration of dust | 10.7±7g/ m³ |
Dust particles | ＜ 150μm |
Blowing sand | |
Air velocity | 18.0 -29.0m/s |
Concentration of sand | 0.18+0.2g/m³; 1.1+0.3g/m³; 2.2+0.5g/m³ |
Sand particles | 149μm - 600μm, 600μm - 850μm |
Controller | Programmable color LCD touch screen controller |
Door Lock | Electromagnetic lock |
Testing Platform Diameter | 600mm |
Testing Platform Speed | 1-7 r.p.m |
Exterior Material | A3 Steel Plate with protective coating |
Interior Material | SUS304 stainless steel |
Power Supply | 380V 50Hz |
Maximum Noise | 65 dBA |
Standard | MIL-STD- 810g |
Design Detail
 |  |
| Workroom | Large Centrifugal Fan |
 |  |
Sand Dust Test Purpose
Blowing sand chamber,Suitable for evaluating the adaptability of all mechanical-electronic, electrical, electrical-electronic, and electromechanical devices that may be exposed to dry sand blowing, dust blowing, or dust falling conditions
Dust Test Capacity Range
Wind speed: 0.1m/s ~ 30m/s
Temperature range: 20℃ to 80℃
Humidity range: 10%-30%RH
Dust fall (blow) : 1g/m3/d ~ 100g/m3/d
Blowing dust test chamber
