Condensation test chambers use condensation humidity to simulate and accelerate damage to metals, paints and organic materials caused by dew. Increasing the temperature of the condensate will show up more quickly than the damage from natural exposure. The condensation chamber only uses tap water for the test, because the evaporation and condensation of the water on the sample is actually a distillation process that removes all impurities.
The LIB condensate test chamber simulates the corrosion of the product by rain and dew on the sample through condensate water.
The condensing test chamber adopts microcomputer PID controller, balanced temperature control, which can control the temperature with high precision and high stability. It can guarantee the safety of long time and high temperature operation. Long service life at the same time. The material of the equipment is imported thickened PVC board, which is corrosion resistant, high temperature resistant and not easy to deformation.
The condensation test chamber can be used for humidity test, and can also be used for low temperature, high temperature and humidity test after improvement. It can reach the specified temperature and humidity point in the test working space and keep it constant. It is commonly used test equipment in major universities, electronic and electrical, automotive and aerospace industries.
Product parameters and characteristics of condensation test chamber:
1. PLC plus touch screen control
2. Inner box size: W600*D500*H300mm
3. Temperature resolution 0.1° C
4. The water level is 100mm high
5, sample window size 80*160mm (or can be customized)
6, sample rack Angle 15 degrees and 60 degrees (switchable) (Angle switch to replacement structure)
7. Test temperature: normal temperature ~70° C
8. Interior box material imported PVC board
9. Outer box material imported PVC board
10. Automatic water refill function
11. Power supply AC220V
12.15 degree sample rack, 60 degree sample rack
The condensation chamber is used to simulate damage to metals, paints and organic materials in areas of high humidity or dew under accelerated conditions. Using the condensate chamber will result in faster results than in a natural environment. The evaporation and condensation process on the test sample is actually a distillation process that removes all impurities. So use tap water as a medium. It should be noted that the condensate test chamber is different from the general humidity test chamber. Condensation test is to expose the product to an environment with relative humidity above 95% for condensation. It's the same principle as the high humidity procedure for the salt spray test.
LIB condensation chamber
|
|
Temperature Range: 10℃ ～ +60 ℃; Humidity Range: 95%RH ~ 100%; Sample shelf:1pc sample shelf + 1pc round bar ; Water trough: Build-in water trough in testing room; Controller: Ethernet connection, USB port; |
LIB can customize the gas fume test chamber for you, which has reached the standard you need to refer to. We are a China-based climate chamber manufacturers that specialize in environmental testing solutions. If you are looking for a cost-effective condensation chamber, then we will be your best choice, please contact us(info@libtestchamber.com)for more information about this device or other environmental test equipment.
