Salt Fog Tester
LIB Industry has many years of rich experience in the production of salt fog tester. All our products are manufactured in strict accordance with the international standard ISO 7253 "Color paints and varnishes - Determination of neutral salt spray resistance".
At present, there are more than thousands of salt-spray test tanks in operation all over the world. The ultra-low failure rate and good consistency make our products highly recognized by customers.
Description
LIB Environmental Simulation Industry is one of the most reliable manufacturers and suppliers of salt fog tester in China, featured by quality products and low price. Welcome to buy CE approved salt fog tester in stock here and get quotation from our factory. Contact us for discount information.
Salt Fog Tester, the necessary instrument for salt spray test. The salt spray test is a method more commonly used today to test the corrosion resistance of coated metal substrates. It is considered to be the most effective method for evaluating the properties of materials closely related to the marine environment, since it can simulate the basic conditions of certain accelerations caused by humidity or temperature, or by both.
Automobile paint
Marine paint
Corrosion protection of steel
Parameter that you may want to know
|
Model |
S-150 |
S-250 |
S-750 |
|
Internal dimensions (mm) |
470*590*400 |
640*1000*500 |
750*1100*500 |
|
Overall dimensions (mm) |
620*1400*1050 |
810*1800*1180 |
920*1900*1200 |
|
Interior Volume (L) |
110 |
320 |
410 |
|
Temperature Range |
Ambient ～ +60 ℃ |
||
|
Temperature Fluctuation |
± 0.5 ℃ |
||
|
Temperature Deviation |
± 2.0 ℃ |
||
|
Humidity Range |
95% ~ 98% RH |
||
|
Salt Fog Deposition |
1～2ml / 80cm2 · h |
||
|
Spray Type |
Continuous / Periodic |
||
Products Classification
1
S type
S-150\ S-250\ S-750\ S-016\ S-010
2
SC type
SC-010\ SC-016\ SC-020
3
SSC type
SSC-010\ SSC-016\ SSC-020
S series is a single salt spray test chamber; SC series is a composite salt spray test chamber, compared with the S series to increase the temperature, humidity, drying and other control parameters; comparing to the SC series, SSC series added the sulfur dioxide test function.
Production Characteristics
|
|
Material
The workroom adopts glass fiber reinforced plastic, which has super anti-corrosion ability and can withstand the high temperature of 120℃.
|
Spray Device
|
|
|
|
The cover of the salt fog tester is made of resin, which can be opened and closed manually because of its light weight. |
INTEGRATED STRUCTURE
The control box is integrated with the test chamber, and the left and right structure is convenient to operate.
INNOVATION
Using water and electricity components isolation design, effectively prevent water into the electrical control box.
PROTECTION FUNCTION
Upper limit temperature alarm, over temperature protection; Heater anti-dry burning device, saturated barrel heater anti-dry burning device, saturated barrel low water level protection.
ANTI-LEAKAGE DEVICE
The workroom seal adopts the water seal mode to ensure that the corrosive gas in the box does not leak.
SPRAY VOLUME COLLECTOR
Spray volume collector (conical funnel) is installed in the working room to monitor the size of spray volume in real time to ensure the test accuracy of test samples.
FOG VENT
The rear side of the test chamber is equipped with a fog vent, which can be operated manually or automatically after the test.
LIB Environmental is one of the professional and credible manufacturers of climatic and environmental testing chambers in China. Equipped with a professional factory, we can offer you the most competitive price of salt fog tester. As long as you have doubts about salt spray corrosion test, want to seek testing solutions, or you are interested in this machine, please feel free to contact us.
Hot Tags: salt fog tester, manufacturers, suppliers, factory, cost, price, used, specification, for sale, B117 Salt Spray Corrosion Test Chamber, cyclic salt corrosion test equipment, Electric Salt Spray Testing Machine, Salt Mist Test Facility, salt spray corrosion test cabinet, Salt spray tester
