IP69K Test Chamber
Model:IP69K Test Chamber;
Standard: IEC 60529, ISO20653;
Controller: Programmable controller;
Door Lock: Electromagnetic lock;
Application:Electronic, street lamp;
Maximum Noise:65 dBA;
Description
Xi'an LIB Environmental Simulation Industry is one of the most reliable manufacturers and suppliers of ip69k test chamber in China, featured by quality products and low price. Welcome to buy CE approved ip69k test chamber in stock here and get quotation from our factory. Contact us for discount information.
IP69K Test Chamber In the IEC 60529 rating system, IP6 refers to the product’s ability to resist ingress of dust. The 9K refers to the product’s ability to resist ingress of high temperature (Steam) / high pressure water.
So IP69K is not a single overall product, but a grouping of two test chambers, IPX9K and IP6X.
IPX9K
IPX9K high pressure and high temperature water spray test chamber is widely used in the electronics, military and consumer product industries. IPX9K is the highest rating currently available for water ingress protection in accordance with IEC 60529 and ISO 20653.
Products under test are subjected to high pressure (8000 – 10000 Kpa), high temperature (+80 °C) and water jets at a flow rate of 14 – 16L/min.
Applications
Automotive Industry
Construction Materials
Outdoor power supply
Underwater camera unit
- Product description
The machine simulates the water pressure of 8000-10000Kpa. It adopts the high-power high-pressure water pump imported from Italy and the specially customized high-pressure solenoid valve, which can accurately control the water pressure and water flow, and the pressure error can be reduced to 0.01Kpa.
The heating tube is located inside the tank, which can ensure the maximum temperature of 88 degrees Celsius. There is a layer of tin foil insulation cotton outside the tank.
The inside of the nozzle is rectangular structure, 0.6*1.7 mm, and the material is cold rolled steel after decarbonization, and the pipe material connecting the nozzle is steel wire silicone resistant to high temperature and high pressure.
- Parameter
 |
IPX9k test equipment,Maximum protection of the load cell against an ingress of water, even with high-pressure or steam cleaning.
|
|
Model |
R9K-1200 |
|
Internal Dimensions (mm) |
1000*1200*1000 |
|
Overall Dimensions (mm) |
1250*1700*2050 |
|
Water Spray Angle |
0°, 30°, 60°, 90° |
|
Water Spray Temperature |
Ambient ~ +88℃ (Adjustable) |
|
Spray Nozzle |
Four, 30 Seconds each position |
|
Distance from Water Spraying to Specimens |
10~15 cm |
|
Water Pressure |
8000-10000 Kpa (Adjustable) |
|
Water Flow Rate |
14L-16L/min |
|
Testing Platform Speed |
5±1 r.p.m |
|
Testing Platform Height |
200-400 nm (Adjustable) |
|
Testing Platform Diameters |
600 mm |
IPX6
IPX6 Dustproof test chamber of IP69K test chamber is suitable for all kinds of auto parts to do dustproof and dustproof test, the test parts include lamp, instrument, electrical dustproof jacket, steering system, door lock and so on.
- Product description
|
|
Vacuum Pump The pressure of the vacuum pump ranges from 0 to 1000 kpa, and the vacuum source is 220V 50Hz 80W vacuum pump. The diameter of the vacuum hose is 0.5 inches. The hose is equipped with water vapor separation device, which can quickly complete the vacuum operation. |
|
|
Built-in Lighting And Built-in Power Supply Dustproof LED lights are installed on the right side of the workroom for illumination and easy observation of the test. The light button is below the controller. There is also an internal power supply (220V/16A) for the measured parts that need to be energized, such as lamps and lanterns.
|
|
|
Circulation pumps 12V 40W mute pump, 0-3L/min flow, maximum pressure of 2KG. The circulation pump is connected to this sealed circulating air duct, no dust leakage and no noise, while the drying device is installed in the air duct to prevent the talcum powder from caking.
|
- Parameter
 |
IP6X sand test equipment,Maximum protection of the load cell against an ingress of dust as well as
|
|
Model |
DI-800 |
|
Internal Dimension (mm) |
800*1000*1000 |
|
Overall Dimension (mm) |
1040*1450*1960 |
|
Interior Volume (L) |
800 |
|
Temperature Range |
Ambient ~ +50℃ |
|
Humidity Range |
< 30% RH |
|
Normal Wire Diameter |
50um |
|
Nominal Width of a Gap Between wires |
75um |
|
Specimen Power Outlet |
Dust-proof socket 16A |
|
Vacuum System |
Equipped with a pressure gauge, air filter, pressure regulator, connecting tube |
|
Standard Configuration |
Sample shelf, dust wiper, talcum powder(5kgs) |
How is the product usually tested
Products rated to IP69K must be able to withstand high-pressure and steam cleaning.
The test specifies a spray nozzle that is fed with 80 °C water at 80–100 bar (~1160-1450) and a flow rate of 14–16 L/min.
The nozzle is held 10–15 cm from the tested device at angles of 0°, 30°, 60° and 90° for 30 seconds each.
The IP69K test device sits on a turntable that rotates once every 12 seconds.
Xi'an LIB Simulation Industry, a focus on environmental test chamber enterprise. If you are interested in this IP69K Test Chamber, please feel free to contact us, we will reply you in the shortest time!
