IPX6K Test Chamber
Water pressure: 1000 Kpa;
Water Flow Rate: 75 L/min +/- 5%for IPX6K;
Internal Diameter of IPX6K Nozzle: 6.3mm;
Turntable Rotation Speed: 1~7 r/min (Adjustable);
Water Supply System: Automatic water supply;
Standard: SUS304 stainless steel;
Name: IPX6K Test Chamber;
Description
Xi'an LIB Environmental Simulation Industry is one of the most reliable manufacturers and suppliers of ipx6k test chamber in China, featured by quality products and low price. Welcome to buy CE approved ipx6k test chamber in stock here and get quotation from our factory. Contact us for discount information.
IPX6K Test Chamber nozzle inner diameter 122.5mm, water flow is 100±5L/min, the main water center part can be adjusted according to the specified water flow
Parameters
|
Model |
R6K-1000 |
|
Workroom dimension (mm) D*W*H |
1000*1000*1000 D*W*H |
|
External dimension (mm) D*W*H |
1150*3350*2100 D*W*H |
|
Interior Volume (L) |
1000 Liters |
|
Diameter of Turntable (mm) |
600 |
|
Turntable loads |
50kgs |
|
Turntable Rotation Speed |
1~7 r/min (Adjustable) |
|
Internal Diameter of IPX6K Nozzle |
6.3mm |
|
Water Flow Rate IPX6K |
75 L/min +/- 5%for IPX6K |
|
Water pressure for IPX6K |
1000 Kpa |
|
Controller |
Programmable color LCD touch screen controller,Ethernet connection, PC Link
|
|
Water Supply System |
Water tank, booster pump, Automatic water supply, Water purification system |
|
Exterior Material |
Steel Plate with protective coating |
|
Interior Material |
SUS304 stainless steel |
|
Standard |
IEC 60529, ISO20653 |
Characteristic
 |
 |
|
Water Re-circulation Water purifier: mainly purification from water source to water tank.. rain re-circulation system that reduced rain use and a series of water pipes. |
Observation window Double-layer tempered glass, specially designed seal, with good impact resistance and prevention of rain leakage. Equipped with manual rain wiper for easy observation samples. |
 |
 |
|
Spray Nozzle Ipx6 waterproof test chamber consists of pressurized water pump, flow meter, water pipe, shunt device, spray bracket and spray nozzles. Rain sprayed from the nozzle, and the flow rate is controlled by electromagnetic flowmeter Equipped with IP5X and IP6X nozzles |
Automatic Water Inlet Automatic control of the water intake of equipment, the customer can be directly connected to the laboratory faucet, so as to achieve automated testing; Automatic inlet diameter 1/2 inch (13.5MM); High and low water level alarm, water shortage lights and sound. Standard 2 meter drain, longer. |
