Sand Simulation Test Cabinet
Temperature: ambient～+50℃;
Dust concentration: 2～4kg/m³;
Blowing time: 0～99H59M;
Place of Origin : China;
MOQ: 1 Set;
Delivery Time : 8-14 days;
Brand: LIB;
Model: 1500L, 2000L;
Door Lock: electromagnetic lock;
Heating Element: nichrome heater;
Humidity Range: < 30% RH;
Normal Wire Diameter: 50um;
Nominal Width of a Gap Between wires: 75um;
Program: 120 programs 20 segment;
Standard:IEC 60529, ISO 20653
Description
LIB Environmental Simulation Industry is one of the most reliable manufacturers and suppliers of sand simulation test cabinet in China, featured by quality products and low price. Welcome to buy CE approved sand simulation test cabinet in stock here and get quotation from our factory. Contact us for discount information.
Sand Simulation Test Cabinet can simulate a lot of sand, dust and desert-like environments to test the product's IP dust resistance, resistance performance, and seal integrity according to the relevant IEC, ASTM and ISO standards. Meet automotive, electronics, military equipment and other testing specifications. The powerful blower intermittently blows compressed air through the fine powdered sand and dust, and then allows the sand and dust to settle down again, covering the product.
Features
Dust concentration range is 2 ～ 4kg / m³；
Humidity control below 30% RH；
Adjustable temperature, the adjustment range is Ambient~+ 50 ℃；
Circulating pump guarantees normal operation of dust spraying system and ensure the dust can be reused；
Equipped with a heating tube to prevent dust from cooling agglomeration;
Mostly used in automotive industry, electronic components, military industry
Basic Parameter
Model | DI-1500 | DI-2000 |
Internal Dimension (mm) | 1000*1500*1000 | 1000*2000*1000 |
Overall Dimension (mm) | 1250*1900*1960 | 1300*2400*1960 |
Interior Volume (L) | 1500 | 2000 |
Parameter | ||
Temperature Range | Ambient ~ +50℃ | |
Humidity Range | < 30% RH | |
Normal Wire Diameter | 50um | |
Nominal Width of a Gap Between wires | 75um | |
Fight Time | 0 ~ 99H59M | |
Blowing Time | 0 ~ 99H59M | |
Structure | ||
Specimen Power Outlet | Dust-proof socket 16A | |
Heating Element | Nichrome heater | |
Vacuum System | Equipped with a pressure gauge, air filter, pressure regulator, connecting tube | |
View Window Size(mm) | 475*475*2 | |
Door Lock | Electromagnetic lock | |
Safety Device | Over-temperature Protection; Over-current Protection; Earth Leakage Protection；Phase Sequence Protection | |
Material | ||
Exterior Material | A3 Steel Plate with protective coating | |
Interior Material | SUS304 stainless steel | |
Observation Window | Interior lighting, double-layer thermo stability silicone rubber sealing | |
Standard Configuration | Sample shelf, dust wiper, talcum powder(5kgs) | |
Power Supply | 380V 50Hz | |
Maximum Noise | 65 dBA | |
Environmental Conditional | 5℃～+35 ℃, 85% RH | |
Standard | IEC 60529, ISO 20653 | |
Configuration
 |  |  |  |
| Workroom | View Window | Heating System | Electromagnetic Lock |
 |  |  |  |
| Internal Power Supply | Controller | Specimen Shelf | Dust Circulating System |
Advantage
• Easy Operation: Dust Testing Cabinet with a new and modern design and Touch style color LCD screen for operation, the end User is free to set and save their testing program.
• Customization Available: Sand blowing Cabinet according to customer’s request, Sanwood can build unique products to meet every need.
• Dust Sand Test Cabinet/Product Performance Standards:IEC 60068-2-68-1994, IEC60529:2001(Protection Provided by Enclosures)
• Telecontrol Support: Each environmental chamber comes standard with a LAN and USB port that can be used to reset and monitor all tests remotely.
• Sample Shelf:
Sample shelf is made of stainless steel, its standard load 50 kgs.
Can custom-make special shelf for heavy samples.
Mesh sieve size is 450*450mm.
