Cyclic Corrosion Testing Chamber

Name: Cyclic Corrosion Testing Chamber Manufacturers, Suppliers, Factory - Cost Price - LIB Industry
Brand: LIB Environmental Simulation Industry
SKU: 242495225

Salt Fog Deposition:1～2ml / 80cm2 · h
Spray Type:Continuous / Periodic
Salt Fog Collected:Fog collector and fog measure cylinder
Air Preheating:Saturated air barrel (31Liter)
Spraying System:Atomizer tower and Spray nozzles
Controller:PID controller
Temperature Sensor:PT100Ω / MV A-class
Standard Configuration:6 round bars and 5 V-shaped grooves
Power Supply:220V 50Hz
Standard:ASTMB117, ISO9227
Name:cyclic corrosion testing chamber

Send Inquiry

Description

LIB Environmental Simulation Industry is one of the most reliable manufacturers and suppliers of cyclic corrosion testing chamber in China, featured by quality products and low price. Welcome to buy CE approved cyclic corrosion testing chamber in stock here and get quotation from our factory. Contact us for discount information.

Description

cyclic corrosion testing chamber is one of the most important equipments for conducting environmental adaptability and reliability tests on protective layers of metal materials, various parts and components, electronic components and industrial products.

Technical Parameters

Name	Cyclic Corrosion Chamber
Model	SC-010	SC-016	SC-020
Internal dimensions (mm)	8001450680	10001600800	10002000900
Overall dimensions (mm)	140025001720	160026501840	160030501940
Interior Volume (L)	780	1280	1800
Temperature Range	+10 ℃ ～ +90 ℃
Temperature Fluctuation	± 0.5 ℃
Temperature Deviation	± 2.0 ℃
Humidity Range	30% ~ 98% RH
Humidity Deviation	+ 2%, - 3%
Salt Fog Deposition	1～2ml / 80cm2 · h
Air Preheating	Saturated air barrel (31Liter)
Spraying System	Atomizer tower and Spray nozzles
Salt Fog Collected	Fog collector and fog measure cylinder
Sealing	Pneumatic seal
Controller	Programmable color LCD touch screen controller, Ethernet connection, PC Link, USB
View Window Size(mm)	800*300
Material	Glass fiber reinforced plastics
Standard Configuration	8 round bars
Standard	IEC60068-2-52, IEC61701-2,ASTM G85,ISO 7253, ASTM B117, ISO9227
Environmental Conditional	5℃～+35 ℃ ≤85% RH

Design


Touch Screen It adopts a touch screen programmable controller to display the test data completely. It can be switched between Chinese and English. The spraying, drying and heat cycle can be controlled completely.	Test Area Internal glass fiber reinforced plastic material, strong corrosion resistance, not easy to break, long service life. The movable round bar and V-shaped groove are provided to facilitate the placement of different shapes of test sample.

Nozzle for cyclic corrosion test chamber After the technical upgrade, the spray tower can adjust the spray volume, The quartz nozzle is resistant to high temperature, not easy to block, and easy to clean.	Material The material adopts a comprehensive anti-corrosion structure, and the high-performance reinforced multilayer glass fiber polyester Resin cabinets and various auxiliary accessories and facilities are also made of temperature-resistant and corrosion-resistant materials, and they have reinforced steel skeletons.
