Vertical Temperature Chamber video

Vertical Temperature Chamber

Name:Vertical Temperature Chamber
Temperature Range:-75℃ ~+220℃;
Model: TS-162\TS-340\TS-500\TS-1000;
Temperature Fluctuation: ± 0.5 ℃;
Temperature deviation:≤±3 ℃;
Standard and Custom;

Description

Xi'an LIB Environmental Simulation Industry is one of the most reliable manufacturers and suppliers of vertical temperature chamber in China, featured by quality products and low price. Welcome to buy CE approved vertical temperature chamber in stock here and get quotation from our factory. Contact us for discount information.



Description




The main application of the Vertical Temperature Chamber is in the electronics industry, where it is used to test the thermal stability of electronic devices such as sensors, circuit boards, and microchips. LIB fully consider the ease of use of the equipment, and its control system is set up very simple and easy to understand.



Product Parameters




Name

Vertical Temperature Chamber

Model

TS-1000

Inner dimensions of test room

850*850*700 mm

Volume of test room

505L

Load of test room

60 kg

Upper limit preheat temperature

+220℃

Heating time

Ambient temperature ~ + 200℃

Lower limit pre-cool temperature

-75℃

Cooling time

Ambient temperature ~ -70℃, within in 30 minutes

High temperature exposure range

Ambient temperature +20 to +200 °C

Low temperature exposure range

–65 to -5 °C



 Structures




Thermal Shock Test Machine (29)

Vertical Thermal Shock Chamber 6

Cable Hole

  • The standard inner hole diameter is 50 mm or 125 mm

 Basket

  • The internal material is 304 stainless steel, mirror surface,

Vertical Thermal Shock Chamber 7

Vertical Thermal Shock Chamber 8

Controller

  • Store test data in real time
  • Mobile APP and PC control

Compressor

  • The compressor is purchased from France TECUMSEH, with reliable quality.



Other Characteristics


◆Safety Device:

Over-temperature protection, Over-current protection; Refrigerant high-pressure protection; Earth leakage protection



◆Temperature and humidity sensor:

 PT-100 class A sensor.



More guarantee




  • 36 months warranty: We will be responsible for solving non-human caused machine failure
  • International certification: LIB's full range of products, including used humidity chamber, are CE and RoHS certified and can be issued with certificates.
