IP6k9k Test Chamber
Mame:IP6k9k Test Chamber
Testing Platform Diameters:600 mm
Turntable loads:50kgs
Power Supply:480V 60Hz 3P
Door Lock:Electromagnetic lock
Description
Xi'an LIB Environmental Simulation Industry is one of the most reliable manufacturers and suppliers of ip6k9k test chamber in China, featured by quality products and low price. Welcome to buy CE approved ip6k9k test chamber in stock here and get quotation from our factory. Contact us for discount information.
IP6k9k test chamber combines the test requirements of IP6K and IP9K in one device, which can meet the test requirements of IPX6,IPX6K,IPX9 and IPX9K at the same time. These testings are designed to provide assurances that a product or device can withstand the most extreme conditions, including being subjected to high-pressure jets of water.
One of the most common places where IP6k9K waterproof testing is used is in the automotive industry. Cars and trucks are subjected to all kinds of weather conditions, and they need to be able to withstand heavy rains, high-pressure water jets, and even floods. By testing the vehicles with IPX9K standards, automobile manufacturers can ensure that their cars and trucks will function properly even in the worst weather conditions.
Another industry where IP6k9K rating waterproof testing is used is in the marine industry. Boats, yachts, and other watercraft must be able to withstand strong currents, waves, and rain. These kinds of tests can ensure that a vessel is waterproof and can withstand harsh conditions while out at sea.
Finally, the food and beverage industry also relies on IP6k9K waterproof testing to ensure that their products are safe for consumption. This kind of testing can be applied to various types of equipment used in food and beverage production, such as washing machines, conveyor belts, and containers. By implementing these tests, manufacturers can reduce the risk of contamination and ensure that their products meet the highest safety standards.
Basic Parameter
|
Model |
R6K9K-1200 |
||
|
Internal Dimensions (mm) |
1000*1200*1000 D*W*H |
||
|
Overall Dimensions (mm) |
1150*3550*2100 D*W*H |
||
|
Interior Volume (L) |
1200 |
||
|
Parameter
|
Testing Platform Diameters |
600 mm |
|
|
Testing Platform Speed |
5±1 r.p.m |
||
|
Turntable loads |
50kgs |
||
|
Testing Platform Height |
200-400 mm (adjustable) |
||
|
IPX6K
|
Internal Diameter of Nozzle |
6.3 mm |
|
|
Water Flow Rate |
75 L/min +/- 5% |
||
|
Water pressure |
1000 Kpa |
||
|
Distance from Water Spraying to Specimens |
between 2.5 m and 3 m. |
||
|
IPX9K
|
Water Spray Angle |
0°, 30°, 60°, 90° |
|
|
Water Spray Temperature |
Ambient ~ +88℃ (Adjustable) |
||
|
Spray Nozzle |
Four, 30 Seconds each position |
||
|
Distance from Water Spraying to Specimens |
10~15 cm |
||
|
Water Pressure |
8000-10000 Kpa (Adjustable) |
||
|
Water Flow Rate |
14L-16L/min |
||
|
Structure
|
Temperature Sensor |
PTR Platinum Resistance PT100Ω/MV A-class |
|
|
Heater Elements |
Nichrome heater |
||
|
Controller |
Programmable color LCD touch screen controller |
||
|
Ethernet connection, PC Link |
|||
|
Build-in Water Tank (mm) |
370*375*950 |
||
|
View Window Size (mm) |
475*475 |
||
|
Door Lock |
Electromagnetic lock |
||
|
Water supply system |
Storage water tank; Booster pump; Automatic water supply; Water purification system; |
||
Product Details
|
|
|
| IPX6K Jet Line: 2.5 m -3 m | IPX9K Jet Nozzle: 4, each nozzle is separated by 30° |
|
|
|
| Pressure Meter: Show the real pressure of the water jet | Workroom: The turntable has pores to facilitate the fixing of test pieces and water leakage. |
If you are interested in this IP6k9k test chamber, please feel free to contact us (info@libtestchamber.com) for more information.
