PV Panel Humidity Freeze Chamber
PV Test:Suits various size PV modules;
Test Temperature: 85℃±2℃;
Relative Humidity: 85%±5%;
Test Duration:1000h;
Panel Capacity:4 / 6 / 8 / 10 / 12 Pieces;
Standard:IEC61215,IEC61646,IEC62688, UL1703,
Free calibration
PV Panel Humidity Freeze Chamber
Description
LIB Environmental Simulation Industry is one of the most reliable manufacturers and suppliers of pv panel humidity freeze chamber in China, featured by quality products and low price. Welcome to buy CE approved pv panel humidity freeze chamber in stock here and get quotation from our factory. Contact us for discount information.
Specially designed by LIB for the solar cell PV module industry, the PV Panel Humidity Freeze Chamber.
Humidity Freeze Chamber accordance with IEC61215 temperature, humidity and heat standard parameters can be carried out various high and low-temperature humidity and heat alternating environment tests.
Technical Specification
| Name | PV Panel Humidity Freeze Chamber |
Model | PV-04 |
Internal Dimension | 1300*700*1350 |
Overall Dimension | 1900*1100*1750 |
Interior Volume | 1220L |
Temperature Range | -60℃～+100 ℃ |
Temperature Fluctuation | ± 0.5 ℃ |
Temperature Deviation | ± 2.0 ℃ |
Humidity Range | 20% ~ 98% RH |
Humidity Deviation | ± 2.5% RH |
Temperature Change Rate | 1~3.4 ℃ / min |
| Panel Size | 1m*2m |
| View Window Size | 330*370(mm) |
| Panel Capacity | 4 / 6 / 8 / 10 / 12 Pieces |
| Build-in Water Tank | 270*300*450(mm) |
| It mainly tests photovoltaic panels and modules |
Multiple language controller
Panel Capacity:4 / 6 / 8 / 10 / 12 Pieces
Cable Hole:Connect the power supply to the PV panel
Clearly view the changes of photovoltaic panels
Structure
●PV thermal cycle machine the shell is made of A3 steel plate, and the surface is sprayed with plastic, which is smooth and beautiful.
● Insulation material: PV test chamber adopt high density glass fiber cotton, insulation thickness of 100mm;
●Mixing system: the use of long shaft fan motor, high and low temperature resistant stainless steel multi-wing impeller, strength convection vertical diffusion circulation;
