UL 153 Rain Test Chamber

Name: UL 153 Rain Test Chamber Manufacturers, Suppliers, Factory - Cost Price - LIB Industry
Brand: LIB Environmental Simulation Industry
SKU: 255634422

Name:UL 153 rain test chamber
Model:R-UL020;
Height adjustment range of spray device:1000-2000mm;
Nozzle spacing:710mm;
Fast delivery;

Send Inquiry

Description

LIB Environmental Simulation Industry is one of the most reliable manufacturers and suppliers of ul 153 rain test chamber in China, featured by quality products and low price. Welcome to buy CE approved ul 153 rain test chamber in stock here and get quotation from our factory. Contact us for discount information.

This standard is mainly used to test portable lamps.

Technical Specification

Model	R-UL020
Overall Dimensions (mm)	80015002200mm
Height adjustment range of spray device	1000-2000mm
Number of spray head	4 spray heads(There are 3 spray heads on the top and 1 spray nozzle on the bottom)
Nozzle spacing	710mm
Spraying Hole Diameter	Φ5mm
Water pressure	34.5Kpa
Sample platform size	500X1500X500
Load of sample platform load	100 Kgs
Water Pressure Control	Flow meter
Water supply system	Automatic water supply, Water purification system
Material	SUS304 stainless steel
Sample platform Material	SUS304 stainless steel
Environmental Conditional	5℃～+35 ℃ ≤85% RH

UL 1703 Water Spray Chamber

You can customize what you need.

Self-constructed closed loop of industrial integration

Realize the closed loop of design, production, and supply chain to ensure the lifeline of quality.

Powerful Brand Influence

LIB have many orders in more than 60 countries, our products are trusted by every customer.

15 Years of Deep Technology Accumulation

Since 2009, we have been committed to the field of environmental reliability testing to continuously create good products.

Powerful customization

We have a wealth of experience in customization, in addition to the standard, there are often customers to make special requests to us.

Product Details

controller

The water pump and controller of the UL 1703 Water Spray Chamber are installed at an independent electric control cabinet separate from the main body.

Spray Head

The number of sprinkler heads is 3, and its aperture is 5mm. The water pressure is 34.5kpa, controlled by the flow meter..

Water supply system

The water inlet is arranged on the left side of the electric control cabinet to supply water to the test body through hoses. The UL 1703 water spray chamber is equipped with a water purification device to prevent poor water quality from clogging the nozzle.
